Especificaciones:
parte No. | HT-HD-0821-SMA-F | |||||
El artículo | Band8-Rx | Band8-Tx | Band3-Rx | Band3-Tx | Band1-Rx | Band1-Tx |
Frecuencia (MHz) | 890-915 | 935-960 | 1710-1760 | 1805-1855 | 1920-1980 | 2110-2170 |
Ancho de banda (MHz) | 25 | 25 | 50 | 50 | 60 | 60 |
Pérdida de la inserción | 1.5dB | 1.5dB | 1.5dB | 1.5dB | − 1.2dB | − 1.0dB |
En banda Ripple | − 1.0dB | − 1.0dB | − 1.0dB | − 1.0dB | − 0.6dB | − 0,5db |
intersección Supresión (MHz) | 45dB @925 | 45dB @1782.5 | 45dB @2045 | |||
| £45@1887.5 | £45@1887.5 | |||||
Aislamiento (dB) | £80@935-960 | 80@890-915 | £80@1805-1855 | 80@1710-1760 | 80@2110-2170 | £80@1920-1980 |
90@1710-1880MHz | 90@1710-1880MHz | 90@890-960MHz | ||||
≥90@1920-2170MHz | ≥90@1920-2170MHz | 90@1710-1855MHz | ||||
VSWR | − 1,25 | |||||
Potencia de entrada (W) | 50W/ por puerto (potencia media) | |||||
Color color | negro | |||||
Temperatura de funcionamiento | -20°C a +65°C | |||||
Temperatura de almacenamiento | -40°C a +85°C | |||||
Relative humedad | 5% - 95% | |||||
Piezas de conexión | SMA-F | |||||
Dimensión, mm | 255*123*47 | |||||
Dibujo del contorno:
Estamos orgullosos de nuestro servicio de atención al cliente y nuestro objetivo es proporcionar un servicio de 5 estrellas. Si tiene alguna pregunta sobre nuestros productos, no dude en llamarnos o enviarnos un correo electrónico.
Llame las 24 horas / 7 días
+86 198-2655-1792A duplexer is a three-port device that enables simultaneous transmission and reception of signals using a single antenna. It isolates the transmitter and receiver to prevent interference, allowing both to operate on different frequency bands. Applications Duplexers are widely used in: Base Stations: Facilitating communication in cellular networks. Repeater Systems: Enhancing signal coverage in large areas. Our Advantages High Performance: Our duplexers offer low insertion loss, high isolation, and excellent durability, ensuring reliable performance in demanding environments. Customization: We provide tailored solutions to meet specific frequency requirements and operational needs.
