Especificaciones:
parte No. | HT-BPF-1415(en millones de ecus) | |
Rango de frecuencia (MHz) | 1430 ~ 1500 | |
Pérdida de inserción (dB) | − 1.0dB | |
La ondul | − 1.0dB | |
rechazo | £30dB@DC-1268MHz 80dB@608-676MHz, 80dB@850-930MHz (GPS L5) (GLONASS G3) 90dB@1207.14MHz(BD B2) 90dB@1227.60MHz(GPS L2) 90dB@1246MHz(GLONASS G2) 90dB@1268.52MHz(BD B3) 1278.45mhz (Galileo E6) | 80dB@1330MHz~1380MHz 90dB@1561.098MHz(BD L1) ≥90dB@1575.42MHz(GPS L1) 90dB@1602MHz(GLONASS G1) 80dB@2400MHz~2500MHz 60dB@2700MHz~4000MHz ≥80dB@4200MHz~4400MHz 60dB@5100MHz~5800MHz ≥50dB@5800MHz~12750MHz |
VSWR | − 1,5 | |
Tipo de conector | SMA-F | |
Tamaño (mm) | 80*70*25MM(incluyendo Conector) | |
Peso (kg) | 0,6 | |
Temperatura de funcionamiento | -20℃~+60℃ | |
Color Color | Chapen de plata | |
El dibujo de esquema
